6Pin with LED Momentary SPST PCB Push Button Click Tact Switch

Model:TS27-1-TW
Switch Action: Momentary (Click)
Circuit: SPST
Switch Rating: 50mA 12VDC

Function: OFF-MOM (Normally Open, Push ON, Release OFF)
LED Working Voltage (40mA Max)
Red:1.8-2.5V
Green:2.8-3.7V
Blue:2.8-3.7V
White:3.0-3.6V
Button Diameter:15mm
Button Color: White + Transparent
Button Travel:0.4±0.15 mm
Operating Force:250±50gf
Solder Specifications:350℃ for 3 Seconds
Weight:1.7g
