Black IP67 protection M20 stuffing locknut plastic waterproof cable gland connector ip67 waterproof connector
Black IP67 protection M20 stuffing locknut plastic waterproof cable gland connector ip67 waterproof connector

Black IP67 protection M20 stuffing locknut plastic waterproof cable gland connector ip67 waterproof connector

Product Tags : Lamp accessoriesconnector
Product Attributes :

Black IP67 protection M20 stuffing locknut plastic  waterproof cable gland connector ip67 waterproof connector




Product Description

1

Model No.waterproof connector
2Housing MaterialNylon(PA66)+GF UL94V-0 1/16''
3Contact MaterialBrass with Gold Plated
4Sealing MaterialSilica Gel
5Contact Number8 Pin
6Contact Resistance<10mΩ
7Insulation Resistance≥500mΩ
8Operating Temperature-25℃ ~ +105℃
9Durability(Plug/Unplug)3000times
10Waterproof RatingIP67
11Screw ThreadM20*1.0
12Thickness of Opening Panel1.5mm-10mm
13Cable Specification20AWG-26AWG
